API 5L Round Ductile Cast Iron Pipes:DN80 ~DN 1200mm,SRL,DRL
Ductile cast iron pipe has also a good anti external pressure, and can reduce the requirements for the tube bed and covering layer manufacturing.It makes the pipe-laying both economical and reliable. In addition, such as the measures to spray zinc,asphalt paint and cement ensure cast pipe of the internal and external anti-corrosion property.
Description
Ductile pipe properties
Ductile cast iron pipe has also a good anti external pressure, and can reduce the requirements for the tube bed and covering layer manufacturing.It makes the pipe-laying both economical and reliable. In addition, such as the measures to spray zinc,asphalt paint and cement ensure cast pipe of the internal and external anti-corrosion property.
Advantages of ductile pipe compared with PE pipe
From the installation time, ductile iron pipe is more easy and convenient to be installed than PE pipe, and bear pressure inside and outside better after the installation.From the airtight property and non-corrosibility,ductile iron pipes have a better seal after installation and can also improve non-corrosibility through many anti-corrosion measures. From the point of view of hydraulic performance, in the conditions of same specification, ductile pipe can realize a greater volume of runoff. From the comprehensive installation and maintenance cost, ductile pipe have more favorable cost-performance ratio.
|
DN(mm) Nominal |
DE(mm) External diameter |
T(mm) Wall thickness |
Socket Weight (kg) |
Unit weight (kg/m) |
Total weight 6000mm(kg) |
Total weight 5000mm(kg) |
(k9) m3/t |
||||||||
|
80 100 125 150 200 250 300 350 400 450 500 600 700 800 900 1000 1200 |
98 118 144 170 222 274 326 378 429 480 532 635 738 842 945 1048 1265 |
K8 6.0 6.0 6.0 6.0 6.0 6.0 6.4 6.8 7.2 7.6 8.0 8.8 9.6 10.4 11.2 12.0 13.6 |
K9 6.0 6.1 6.0 6.3 6.4 6.8 7.2 7.7 8.1 8.6 9.0 9.9 10.8 11.7 12.6 13.5 15.3 |
K10 6.0 6.1 6.3 6.3 6.4 7.5 8.0 8.5 9.0 9.5 10.0 11.0 12.0 13.0 14.0 15.0 17.0 |
3.4 4.3 5.7 7.1 10.3 14.2 18.9 23.7 29.5 38.3 42.8 59.3 79.1 102.6 129.0 161.3 237.7
|
K8 12.2 14.9 18.3 21.8 28.7 35.6 45.3 55.9 67.3 80 92.8 122 155 192 232 275 374 |
K9 12.2 15.1 18.3 22..8 30.6 40.2 50.8 63.2 75.5 89 104.3 137.3 173.9 215.2 260.2 309.3 420.1 |
K10 12.2 15.1 19 22.8 30.6 44.3 56.3 69.6 83.7 99 115.6 152 193 239 289 343.2 466.1 |
K8 76.5 93.7 119 138 183 228 290 359 433 515 600 791 1009 1255 1521 1811 2482
|
K9 76.5 95 119 144 194 255 323 403 482 574 669 882 1123 1394 1690 2017 2758
|
K10 76.5 95 121 144 194 280 357 441 532 632 736 971 1237 1537 1863 2221 3034
|
K8 64.4 78.8 97.2 116.1 153.8 192.2 245.4 303.2 366 438.3 506.8 669.3 854.1 1062.6 1289 1536.3 2107.7
|
K9 64.4 79.8 97.2 121.1 163.3 215.2 272.9 339.7 407 483.3 564.3 745.8 948.6 1178.6 1430 1707.8 2338.2
|
K10 64.4 79.8 100.7 121.1 163.3 235.7 300.4 371.7 448 533.3 620.8 819.3 1044.1 1297.6 1574 1877.3 2568.2
|
1.3 1.52
2 2.27 2.48 2.69 2.65 2.6708 2.7839 2.8969 3.0861 3.2582 3.4304 3.6 3.6257 |
